Product Description

Stainless Steel Seine Pulley Block

Seine blocks are pulley blocks that can also redirect wire rope when needed.

These Pulley Blocks have a swivel eye on the top and they are primarily used within the marine industry, however they are also suitable to be used within other industries too.

The spring loaded gate allows for easy insertion of rope and thanks to it's design the wire rope can't come out again once in place.

With a solid metal sheave and a strong outer casing these blocks are built to last, and thanks to the Stainless Steel finish they are protected from the harsh marine environment.

Thanks to the metal sheave these are suitable for both soft and wire ropes.

Not to be used for lifting

Size  Suitable for Rope Size A (MM) B (MM) C (MM) D (MM) E (MM) Breaking Load (KG)
50MM  14MM 155 50 19 27.5 14.3 1400
75MM 15MM 222 76 24 40 14.7 3500
75MM 22MM 222 76 24 40 22 3500
100MM 19MM 260 100 24 37 17.5 5000

Specifications

Product Code
SFSSSBS050
Weight
0.6kg

Customer Reviews

Stainless Steel Seine Pulley Block with Eye (50MM - 100MM Wire Rope Metal Sheave Marine Pulling)

Item in Stock

Product Code SFSSSBS050

These Stainless Steel Pulley Blocks are ideal for Marine applications.
