Product Description

Manual, Hydraulic & Semi Electric Hand Stackers from 0.5 Ton to 2 Ton & 1.1 Metre to 2.5 Metre

Hand Stackers are universally renowned for their practicality and safety while in use at job sites. When a Forklift isn't available, and the use of a Crane too unsafe, there's no easier way to lift pallets to high places. You can count on our Heavy Duty Hand Stackers to get your pallets where they need to be.

With a simple one man operation, this Hand Stacker is uncomplicated to control. The Stacker is operated through a lever that gradually pumps the forks up when pulled downwards. For hastier lifting, a foot pump is situated bellow the lever. The handle at the top of the lever is used to bring the forks down, or lock and prevent the handle from lifting any further. This particular Stacker is compact, making it ideal for small scale lifting.

While being able to turn 360° on the spot, the rear wheels also have a foot break catch, for added safety. A bright orange coat of paint applies a factor of high visibility, once again complimenting this Stackers safety features. The forks are kept steady as the Stacker is wheeled around, helping to prevent any items falling off.

Lift and Capacity Max Capacity At 0.5 Metre Max Capacity At Max Height Fork Width x Length Overall Fork Width Loading Centre On Forks Minimum-Maximum Fork Height Lifting Height Per Stroke Overall Length x Width x Height Overall Height When Fully Raised
0.5T / 1.1M Lift 0.5 Ton 0.5 Ton 165MM x 885MM 565MM 440MM 90MM - 1170MM 35MM 1460MM x 590MM x 1645MM 1645MM
1T / 1.6M Lift 1 Ton 0.75 Ton 160MM x 1150MM 520MM 600MM 85MM - 1635MM 25MM 1750MM x 710MM x 2040MM 2040MM
1T / 2.5M Lift 1 Ton 0.5 Ton 150MM x 1150MM 530MM 600MM 85MM - 2590MM 15MM 1740MM x 730MM x 1840MM 3150MM
1.5T / 1.6M Lift 1.5 Ton 1.1 Ton 160MM x 1160MM 530MM 600MM 85MM - 1630MM 10MM 1740MM x 730MM x 2040MM 2040MM
1.5T / 2.5M Lift 1.5 Ton 0.5 Ton 150MM x 1150MM 530MM 600MM 80MM - 2590MM 15MM 1740MM x 730MM x 1840MM 3150MM
1.5T / 2.5M lift (Semi Electric) 1.5 Ton 1 Ton 160MM x 1155MM 550MM 600MM 85MM - 2530MM -- 1835MM x 745MM x 3050MM 3050MM
2T / 1.6M lift 2 Ton 1.5 Ton 160MM x 1160MM 530MM 600MM 85MM - 1630MM 10MM 1740MM x 730MM x 2040MM 2040MM

These stackers are brand new.

Minor surface marks may be present due to handling during storage and transportation, but these do not affect the product’s functionality or performance.

Specifications

Max Capacity At 0.5 Metre:
1.5 Ton
Max Capacity At 0.5M:
1000KGS (1.0 Ton)
Max Capacity At 2.5 Metre
0.5 Ton
Max Capacity At 1.6 Metre:
1100KGS (1.1 Ton)
Max Capacity at 1.6M:
1500KG (1.5 Ton)
Fork Width x Length
165MM x 885MM
Max Capacity At 2.5M:
500KGS (0.5 Ton)
Overall Fork Width
565MM
Loading Centre On Forks
440MM
Lifting Height Per Stroke
35MM
Minimum-Maximum Fork Height
80 - 2590MM
Overall Length x Width x Height
1460MM x 590MM x 1645MM
Height When Lowered
1850MM
Overall Height When Fully Raised:
2040MM
Product Code
SFAPPA0515
Weight
220kg

Customer Reviews

Hand Pallet Stacker Truck , Manual, Hydraulic & Semi Electric 0.5 Ton - 2 Ton , 1.1M - 2.5M

Item in Stock

Product Code SFAPPA0515

This Hand Stacker is compact compared to other Stackers, making it perfect for small scale lifting.
